PERFORMANCE |
|
Measured Value |
RMS Value Velocity or Peak Value Displacement |
Input |
Single Channel with 2 relay O/P |
|
Velocity: 0-2/5/10/20/50 mm/Sec |
Displacement: 0-20/50/100/200/500µm |
|
Freq. Range |
10-1000Hz |
Analog Output |
4-20mA |
Accuracy |
<3% |
ELECTRICAL |
|
Working Resistance |
≤500Ω |
Load Resistance |
≥100KΩ |
Supply Voltage |
230/110V AC 50HZ or 24V DC |
MECHANICAL |
|
Case Material |
Sturdy Aluminium |
Dimension |
235x168x112 mm L×W×H |
Weight |
3.60 Kg |
ENVIRONMENTAL |
|
Operating Temperature |
- 30º …. + 65º C |
Storage Temperature |
- 40º …..+ 100º C |
Sealing |
IP65 |
Humidity |
Max. 95 % , non-condensing |
-------------------------------------------------------------------------------------------
